ON GRID solar systems (no batteries)

HYBRID (on-grid solar systems with batteries)

OFF GRID solar systems

(No grid power to property, Stand-Alone)

NEVER PAY A POWER BILL AGAIN!

5kw Standalone Power System (Off-Grid) Indicative Costs

VV Electrical and Solar – Victron Premium

10Kva (16kwh/day Winter – 25kwh/day Summer)

————————————————————————————————————-

Load: The loads key elements comprise:- medium A/C unit, Refrigerators (x2), Freezers (x2), oven, hot plates, LED TV’s (x1) IT Equipment, LED lighting internal and external, tablet/phone charging. Energy usage greatest during the day.

Non-Electrical appliances: combustion heating.

Overview:

  • Daily demand – Summer 21kwh/day, Winter 16kwh/day
  • Continuous AC power:8000kva @25c
  • Maximum load :16,000W
  • 2.5 hrs peak sun hours worst month
  • Estimated maximum solar yield 11.300kwh/yr
  • Depth of discharge based on 1 days approximately 30-50% daily
  • Estimated fuel (diesel) use 250-350L/yr

Components and Inclusions:

  • Victron Multiplus 25/5000 Inverter Charger 7000w @25c (16,000w peak @25c)
  • Victron Blue solar charge controllers x2  MPPT  150/100
  • Battery Bank 2200ah Victron GEL.
  • VIctron Colour Control installed
  • 5.0kw Solar PV array 18x 275w c-sun panels.
  • 7kva Auto start Diesel generator
  • Tin roof mounting system
  • Battery cabling and installation +DC disconnect.
  • Electrical kit for solar isolation and protection.
  • Auto Start Configuration of Generator (if available)
  • Installation and commissioning
  • Certificate of Electrical Safety with STC compliance, manuals and documentation.

Recommendations:

  • Diesel silenced generator sized to the system approximately  6kva Budget: ADD $5840.00 + installation and underground cable run per meter: $108 per mtr.

Options and/or potential costs:

  • Construction of battery room
  • Battery rack
  • Trenching $108 per meter
  • Ground mount frames
  • Council development assessment approval – if tilt legs are used.
  • Electrical distribution and circuit wiring
  • Travel and accommodation (if required) for the installation team.

Indicative Pricing: Kit with installation: $31.608.00 inc gst.

SMA 5.5kw

20Kva (9kwh/day Winter – 20kwh/day Summer)

—————————————————————–

Load: The loads key elements comprise:- medium A/C unit, Refrigerators (1), Freezers (1), oven, hot plates, LED TV’s (x1) IT Equipment, LED lighting internal and external, tablet/phone charging. Energy usage greatest during the day.

Non-Electrical appliances: combustion heating.

Overview:

  • Daily demand – Summer 20kwh/day, Winter 9kwh/day
  • Continuous AC power:8000kva @25c
  • Maximum load :16,000W
  • 9 hrs peak sun hours worst month
  • Estimated maximum solar yield 27,400kwh/yr
  • Depth of discharge based on 1 days approximately 50-80% daily
  • Estimated fuel (diesel) use 250-350L/yr

Components and Inclusions:

  • SMA Sunny Island 8kva 48v inverter/charger
  • SMA Sunny Island PV Inverter, dual tracker 5kw
  • IPAD for display in house
  • Battery Bank 1x BYD 13.8kwh lithium-ion battery
  • 5kw Solar PV array 18 x 305w Q-Cell tier 1 premium panels
  • Tin roof mounting system
  • Battery cabling and installation +DC disconnect.
  • Electrical kit for solar isolation and protection.
  • Auto Start Configuration of Generator (if available)
  • Installation and commissioning
  • Certificate of Electrical Safety with STC compliance, manuals and documentation.

Recommendations:

  • Diesel silenced generator sized to the system approximately 10kva Budget: ADD $9840.00 + installation and underground cable run per meter: $108 per mtr.
  • Options and/or potential costs:
  • Construction of battery room
  • Battery rack
  • Trenching $108 per meter
  • Ground mount frames
  • Council development assessment approval – if tilt legs are used.
  • Electrical distribution and circuit wiring
  • Travel and accommodation (if required) for the installation team.

Indicative Pricing: Kit with installation: $32,780 inc gst.

Standalone Power System (Off-Grid)Indicative Costs

VV Electrical and Solar – SMA Premium 10kw

20Kva (21kwh/day Winter – 40kwh/day Summer)

—————————————————————————————————————

Load: The loads key elements comprise:- medium A/C unit, Refrigerators (x2), Freezers (x2), oven, hot plates, LED TV’s (x1) IT Equipment, LED lighting internal and external, tablet/phone charging. Energy usage greatest during the day.

Non-Electrical appliances: combustion heating.

Overview:

  • Daily demand – Summer 40kwh/day, Winter 18kwh/day
  • Continuous AC power:8000kva @25c
  • Maximum load :16,000W
  • 2.5 hrs peak sun hours worst month
  • Estimated maximum solar yield 27,400kwh/yr
  • Depth of discharge based on 1 days approximately 30-50% daily
  • Estimated fuel (diesel) use 250-350L/yr

Components and Inclusions:

  • SMA Sunny Island 8kva 48v inverter/charger
  • SMA Sunny Boy PV inverter 5kw (x2)
  • 10kw Solar PV array 32x 305w Q-Cell panels.
  • BYD lithium-ion batteries 13.8kwh each x 2
  • Tin roof mounting system
  • Battery cabling and installation +DC disconnect.
  • Electrical kit for solar isolation and protection.
  • Auto Start Configuration of Generator (if available)
  • Installation and commissioning
  • Certificate of Electrical Safety with STC compliance, manuals and documentation.

Recommendations:

  • Diesel silenced generator sized to the system approximately 10kva Budget: ADD $9840.00 + installation and underground cable run per meter: $108 per mtr.

Options and/or potential costs:

  • Construction of battery room
  • Battery rack
  • Trenching $108 per meter
  • Ground mount frames
  • Council development assessment approval – if tilt legs are used.
  • Electrical distribution and circuit wiring
  • Travel and accommodation (if required) for the installation team.

Indicative Pricing: Kit with installation: $47,490.00 inc gst.

Standalone Power System (Off-Grid)Indicative Costs

VV Electrical and Solar – SMA Premium 15kw

(31kwh/day Winter – 60kwh/day Summer)

——————————————————————————————————————

Load: The loads key elements comprise:- medium A/C unit, Refrigerators (x2), Freezers (x2), oven, hot plates, LED TV’s (x1) IT Equipment, LED lighting internal and external, tablet/phone charging. Energy usage greatest during the day.

Non-Electrical appliances: combustion heating.

Overview:

  • Daily demand – Summer 60kwh/day, Winter 31kwh/day
  • Continuous AC power:16,000kva @25c
  • Maximum load :32,000W
  • 9 hrs peak sun hours worst month
  • Estimated maximum solar yield 37,400kwh/yr
  • Depth of discharge based on 1 days approximately 30-50% daily
  • Estimated fuel (diesel) use 250-350L/yr

Components and Inclusions:

  • SMA Sunny Island 8kva 48v inverter/charger c(x2) (16kvA)
  • SMA Sunny Island dual tracker, 5kw (x3)
  • Battery Bank: 3 x BYD Lithium-ion batteries 13.8kwh total 41.4kwh
  • 15kw Solar PV array 50x 305w Q-Cell Tier 1 panels.
  • Tin roof mounting system
  • Battery cabling and installation +DC disconnect.
  • Electrical kit for solar isolation and protection.
  • Auto Start Configuration of Generator (if available)
  • Installation and commissioning
  • Certificate of Electrical Safety with STC compliance, manuals and documentation.

Recommendations: (not included)

  • Diesel silenced generator sized to the system approximately 10kva Budget: ADD $13840.00 + installation and underground cable run per meter: $108 per mtr.

Options and/or potential costs:

  • Construction of battery room
  • Battery rack
  • Trenching $108 per meter
  • Ground mount frames
  • Council development assessment approval – if tilt legs are used.
  • Electrical distribution and circuit wiring
  • Travel and accommodation (if required) for the installation team.



Indicative Pricing: Kit with installation: $67,490.00 inc gst.

Check out the Video for a look:

15kw Offgrid

20KW, 3 Phase, Off-Grid Installation.

55.2kwh of Lithium phosphate batteries.

VV can help you get solar today.

Need to go solar but don’t have the cash up-front? with VV’s payment plan options (provided by Ratesetter) you can buy your solar system today and pay nothing up front and pay off the balance in low installments!
